• 16 input with 16 internal busses
• 12 professional mic input channels
• 2 stereo inputs
• 8 configurable smart outputs
• 7″ high resolution touch screen
• 9 motorised 100mm faders
• Advanced hybrid user interface

Mic Inputs                          12 (8x XLR / 4x Combo XLR)

Stereo Inputs                     2

Master Output                  2 (Left/Right balanced XLR)

Smart Outputs                  6 (assignable balanced XLR)

Internal busses                16

Stage monitor                   1 TRS Jack output

Headphone                        1 TRS Jack output

Screen                                  7″ high definition touch screen

Faders                                  8x motorised 100mm channel faders + 1x motorised 100mm master L/R mix

Operation system            Android system

Remote system                IOS app for Ipad

Network                              Yes, via WiFi module

Sample Frequency           48 KHz

AD/DA                                  192 KHz, 24-bit

DSP                                        40 bit float point, SHARC processor

Effects                                  up to 8 assignable effect modules

AES/EBU                              Output XLR

S/PDIF                                  Input / Output (RCA Phono)

USB Interface                    2 for playback/recording, scene/setting storage and system updates

Power Supply                    90-240V ~ 50/60Hz power supply 12VDC

Dimension W*H*D          357 x 480 x 145 (mm)
